Descriptive abstract
Widely used for the milk powder, health product, spice product and snack food etc.
Main features
1: Fully stainless steel structure and compact design.
2: Sealing tightly and effectively protect filled powder quality
3: The negative pressure inside the sealed cans is adjustable to remove the persistent ailment of "buckled can".
4: The gas inside the cans is effectively replaced which will greatly prolonging product shelf life.
5:Applicable range including milk powder, health powder product ,condiments ect.
6: Can be only used to seam round shaped cans( Hard paper or metal structure) ,cans dimension range: Dia70-131 Height 100-190mm with different seaming tools.
7: Seaming Capacity 13-14Cans per min , remaining oxygen is under 3%.
Main Technical Data
Model | DH-FK-502 |
Speed | 13-14 cans/min |
Remaining oxygen | ≤3% |
Can size | φ73─φ131mm/H100-190mm |
Power supply | 3Phase 208-415V 50/60Hz |
Total power | 9.1kw (Include Vacuum pump 3kw) |
Air supply | 6kg/cm 0.25cbm/min |
Need Nitrogen | 10cbm/hour/set |
Nitrogen | Purity >99.99%,Pressure:0.4Mpa |
Overall dimension | 1400*1000*1894mm |
Total weight | 800kg |
1. Are you factory or trading company?
We are factory with 20 years experience. Rich experience in the powder filling machine field.
2. Can i visit your factory and send team for learing and inspect?
Yes, sure. Welcome to visit us!
3. What's your warranty and after-sale service?
One year warranty and lifelong after-sale service via skype/email/mobile/whatsapp.
4. What is the payment term?
30% T/T deposit and 70% T/T balance payment before shipping.
5. How long is the delivery time?
About 20- 40 working days.
