Feature:
1.Double jacketed(warp and weft by high strength polyester filament with low elongation)
2.Lining:PU light weight and cheap,used for fire fighting or Agricultural irrigation,service long life and aging.
3.extreme weather conditions:-40ºF to 176ºF (-40ºC to 80ºC)
4.smooth inner waterway, yielding an extremely low friction loss for maximum flow
5.Easy to roll and carry, good for quick installation and emergence use
6.Also can transport water and other chemical solution
Application
Industrial and municipal fire brigades
Military
Marine fire fighting
Interior rack and reel hose
Commercial and civil engineering
Filed irrigation and garden irrigation
Also can be used to transport drinking water
Couplings available
Storz couplings & John Morris couplings & American couplings or other type on your request.
Color
Orange,red and black are available or others on your request.
Standard
Fire hose manufactured to this specification shall meet and exceed all performance requirements of CCC,ISO9001:2008.
Standard length
15m,20m,25m,30m,Other length on your request.
Feature:
1.Double jacketed(warp and weft by high strength polyester filament with low elongation)
2.Lining:PU light weight and cheap,used for fire fighting or Agricultural irrigation,service long life and aging.
3.extreme weather conditions:-40ºF to 176ºF (-40ºC to 80ºC)
4.smooth inner waterway, yielding an extremely low friction loss for maximum flow
5.Easy to roll and carry, good for quick installation and emergence use
6.Also can transport water and other chemical solution
Application
Industrial and municipal fire brigades
Military
Marine fire fighting
Interior rack and reel hose
Commercial and civil engineering
Filed irrigation and garden irrigation
Also can be used to transport drinking water
Couplings available
Storz couplings & John Morris couplings & American couplings or other type on your request.
Color
Orange,red and black are available or others on your request.
Standard
Fire hose manufactured to this specification shall meet and exceed all performance requirements of CCC,ISO9001:2008.
Standard length
15m,20m,25m,30m,Other length on your request.
| Technical Requirements | Temperature Range | length | |||
| Size (Inch/mm) | Working Pressure (Bar/Psi) | Burst Pressure (Bar/Psi) | -40ºF to 176ºF (-40ºC to 80ºC) | 15-30m/50-100FT | |
| 1" | 25 | 20/300, 28/400, 30/450, 40/600 | 60/900, 84/1200, 90/1350, 120/1800 | ||
| 1-1/2" | 38 | 20/300, 28/400, 30/450, 40/600 | 60/900, 84/1200, 90/1350, 120/1800 | ||
| 1-3/4" | 45 | 20/300, 28/400, 30/450, 40/600 | 60/900, 84/1200, 90/1350, 120/1800 | ||
| 2" | 52 | 20/300, 28/400, 30/450, 40/600 | 60/900, 84/1200, 90/1350, 120/1800 | ||
| 2-1/2" | 65 | 20/300, 28/400, 30/450, 40/600 | 60/900, 84/1200, 90/1350, 120/1800 | ||
| 3' | 80 | 20/300, 28/400, 30/450, 40/600 | 60/900, 84/1200, 90/1350, 120/1800 | ||
| 3-1/2' | 90 | 20/300, 28/400, 30/450, 40/600 | 60/900, 84/1200, 90/1350, 120/1800 | ||
